OSRAM KW CSLNM1.TG (1mm2) & Osram KW CSLPM1.TG (2mm2)

646 posts / 0 new
Last post
ZozzV6
ZozzV6's picture
Offline
Last seen: 2 days 3 hours ago
Joined: 03/24/2016 - 12:19
Posts: 2158
Location: Near to my soldering iron.

I wonder what results will be if these high cd flashlights measured at 15-20m. Just my mind working. if you read a super range thrower at 5m a very nice number but at 15-20m read much lower numbers you read wrong. Because the beam focused to 5m. And at bigger distances it will widening out and loose intensity. I always measure throwers at 10-15-20-25m and try to focus the light to get the highest intensity at 20-25m readings.

tvizk
Offline
Last seen: 4 hours 17 min ago
Joined: 06/09/2018 - 10:58
Posts: 71
ZozzV6 wrote:
I wonder what results will be if these high cd flashlights measured at 15-20m. Just my mind working. if you read a super range thrower at 5m a very nice number but at 15-20m read much lower numbers you read wrong. Because the beam focused to 5m. And at bigger distances it will widening out and loose intensity. I always measure throwers at 10-15-20-25m and try to focus the light to get the highest intensity at 20-25m readings.

I’ll try to do that when I have the time. I managed to get 1600m. I compared the beam to an Olight M3X and it blew that out the water. Also compared it to a Nitecore TM38 and beam was still tighter though.

eas
eas's picture
Offline
Last seen: 2 days 13 hours ago
Joined: 07/14/2014 - 18:53
Posts: 1354
Location: PNW

Put one in a VG-10-ish host using a 3A buck driver. The reflector is about 23mm diameter.

I’d say the hotspot diameter is about 10% larger than that of my XPL-HI Convoy L2 Big Smile

Next, I want to bump it up to ~5A or so.

I have two more of these emitters. I think one is going in a C8. The other will go into either my L2, or into an Eagle Eye X6.

.

-X3-
-X3-'s picture
Online
Last seen: 1 min 22 sec ago
Joined: 07/16/2014 - 03:28
Posts: 2566
Location: France, Angers
tvizk wrote:
ZozzV6 wrote:
I wonder what results will be if these high cd flashlights measured at 15-20m. Just my mind working. if you read a super range thrower at 5m a very nice number but at 15-20m read much lower numbers you read wrong. Because the beam focused to 5m. And at bigger distances it will widening out and loose intensity. I always measure throwers at 10-15-20-25m and try to focus the light to get the highest intensity at 20-25m readings.

I’ll try to do that when I have the time. I managed to get 1600m. I compared the beam to an Olight M3X and it blew that out the water. Also compared it to a Nitecore TM38 and beam was still tighter though.


You should try it in the M3X as well, it’s stunning !

"-X3-, is there any place in your house without a flashlight ?"

My Flashlight public album (mods, emitter swaps, eye candy)

My reviews channel (French language, Olight, Thorfire, Sofirn, Lumintop : 60+ lights tested)

My personal channel (including Olight SR mini, S1, S2, S1A and S-mini disassembly)

M4DM4X blog, saves you $$$

tvizk
Offline
Last seen: 4 hours 17 min ago
Joined: 06/09/2018 - 10:58
Posts: 71
X3 wrote:
tvizk wrote:
ZozzV6 wrote:
I wonder what results will be if these high cd flashlights measured at 15-20m. Just my mind working. if you read a super range thrower at 5m a very nice number but at 15-20m read much lower numbers you read wrong. Because the beam focused to 5m. And at bigger distances it will widening out and loose intensity. I always measure throwers at 10-15-20-25m and try to focus the light to get the highest intensity at 20-25m readings.

I’ll try to do that when I have the time. I managed to get 1600m. I compared the beam to an Olight M3X and it blew that out the water. Also compared it to a Nitecore TM38 and beam was still tighter though.


You should try it in the M3X as well, it’s stunning !

I would if have it. The M3X and TM38 was a friend’s one.

-X3-
-X3-'s picture
Online
Last seen: 1 min 22 sec ago
Joined: 07/16/2014 - 03:28
Posts: 2566
Location: France, Angers

I plan to put one in an M2X in a few days.
I’ll tell you how it turned out

"-X3-, is there any place in your house without a flashlight ?"

My Flashlight public album (mods, emitter swaps, eye candy)

My reviews channel (French language, Olight, Thorfire, Sofirn, Lumintop : 60+ lights tested)

My personal channel (including Olight SR mini, S1, S2, S1A and S-mini disassembly)

M4DM4X blog, saves you $$$

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

I put one in a Supfire F5, that was housing a dedomed XP-G S4 2B before. It did exactly 100kcd with the XP-G2. It is not a well-known light, a well-built 18650 zoomie with effectively 26mm plastic lens, here’s a pic.

Everything was done thermally as good as possible in this host. I first removed both spring bypasses and then added them again one by one because I hoped to get into the 130’s kcd. I ended with 120 kcd at start, 110 kcd at 30 seconds (with 500lm flood, 165lm spot). Still an improvement over the dedomed S4 2B, and certainly a better tint and beam shape, and contrary to the S4 2B the throw will hardly go down when the battery drains.

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

Btw, the Supfire F5 was always overpriced at 30 dollars but now I found it for 16.63 dollar shipped.
https://www.aliexpress.com/item/Mini-Led-Flashlight-CREE-L2-1100-Lumens-...

luminarium iaculator
luminarium iaculator's picture
Offline
Last seen: 2 days 28 min ago
Joined: 07/07/2013 - 09:09
Posts: 2251
Location: X
djozz wrote:
Btw, the Supfire F5 was always overpriced at 30 dollars but now I found it for 16.63 dollar shipped. https://www.aliexpress.com/item/Mini-Led-Flashlight-CREE-L2-1100-Lumens-...

Dang! I am buying new EDC but I need something that won’t turn on accidentally in my pocket. But now you came with 120KCD for this tiny zoomie and that is OMG Thumbs UpBeer

Could you help me out in this thread Djozz? I mean Ultratac S20 thread http://budgetlightforum.com/comment/1413754#comment-1413754 I don’t know if you bought that light?

Edit:

Tail cap readings on your freshly modded supfire? Does it has anodized threads at the tailcap?

Just saw your review of Supfire 5 http://budgetlightforum.com/node/42186

I think on one pic is seen that it does not has anodized tailcap tube and switch threads. When flashlight has anodized threads we can turn it on/off with twist to turn move or just unscrew tailcap slightly to prevent accidentally turning on.

Modding is making something how you want it to be, not how it comes stock...

Old-Lumens

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

I never bought the S20 so I can not give an impression.

This F5 has bare tail threads, so no lock-out there. But with tail clickies I do not usually have problems switching it on in my pocket.

Btw, the F5 has a 20mm driver, and back in 2015 I did a review on it: http://budgetlightforum.com/node/42186

polarweis
polarweis's picture
Offline
Last seen: 1 day 21 hours ago
Joined: 05/31/2017 - 17:05
Posts: 333

i would like to buy a cometa and put this led in there. which driver would be best? and do i need to think about something else? just the host driver and led right?

"It wouldn’t be so bright if there wasn’t a shadow every once in a while." - Jason Mraz

nkresho
nkresho's picture
Offline
Last seen: 3 hours 27 min ago
Joined: 11/26/2017 - 20:36
Posts: 215
Location: Pittsburgh, PA, USA
If you’re gabbing the led from them, why not get the L4p driver? You can pick your current.
djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

I made a Cometa (from the recent trash sale on BG) with a KW CSLNM1-TG led (on stock 20mm Manker board soldered to pill) and 12-chip biscotti driver, it is doing 4.14A and 299 kcd at 30 seconds (and pretty steady at that).

I hope that the wavien collar that I will try to add next works well on this led.

It is full moon now so I could not resist the moon beam shot:

AlexGT
AlexGT's picture
Offline
Last seen: 27 min 39 sec ago
Joined: 06/07/2012 - 17:39
Posts: 4193
Location: Texas

Do warmer tints exist for this emitter? Maybe something in t he 5000k range?

SKV89
Offline
Last seen: 6 hours 42 min ago
Joined: 12/10/2017 - 12:46
Posts: 2303
Location: US

300kcd sweet! Did it take effort to focus the emitter?

Can’t wait to see your pics on setting up the wavien collar. I also have one waiting to be used so this will be very helpful! LOL

Sirius9
Sirius9's picture
Offline
Last seen: 21 hours 1 min ago
Joined: 03/04/2012 - 19:23
Posts: 4483
Location: South Europe

I wonder, how well would smaller reflector lights throw with this emitter!
For example, S2+ with SMO reflector and this led, and lets say 5A driver, what throw would we get!



djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

Btw, I measured the hotspot of my Cometa mod at 8800K. I checked a LX1010B luxmeter against my Mobilux class A luxmeter, for this hotspot my LX1010B (that for neutral leds under-reads) measures 340 kcd which is more than 13% high (LX1010B calibrations may vary Silly )

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

SKV89 wrote:
300kcd sweet! Did it take effort to focus the emitter?

Can’t wait to see your pics on setting up the wavien collar. I also have one waiting to be used so this will be very helpful! LOL


The led is on the stock board and is about as thick as the stock XP-L Hi, so the focus is fine.
KawiBoy1428
KawiBoy1428's picture
Offline
Last seen: 1 hour 42 min ago
Joined: 04/11/2014 - 18:05
Posts: 3396
Location: The Motor City

Moon

Moon meets Flat White Tree meets Flat White Pretty intense focused spot Kodi wants the Turbo Flat White…he is eye balling it Intensely….

KB1428 “Live Life WOT”

ImA4Wheelr
Offline
Last seen: 3 hours 42 sec ago
Joined: 02/03/2013 - 14:51
Posts: 7872
Location: SC

Not finished yet.  So just reporting some info for those wanting to swap this emitter into a MF04.  Used a thin solder layer as recommended and lapped the stock MCPCB and the emitter shelf.  Used an old MT07 buck driver set to 4 amps.  Using the stock MF04 reflector isolation ring the beam is not quite focused.  At the moment, the emitter is not quite centered (but appears close) and it is visible in the beam.  The hot spot is not sharply defined.  I only measured 1.3kcd at 10.85 meters.  I can't find my favorite light meter to verify this reading.  The light is way too big for my integrating tube.  So no lumen measurements to report.  No indications of thermal sage noted.

Not sure what direction I need to move the emitter yet.  I think it's too high in to the reflector. The heat sinking with the large MCPCB and host makes me think I can probably up the current to 4.75-5 amps.  Any suggestions on that from you folks using this emitter in bigger lights yet?

I'll report on progress when I get another chance to work on the light.  If anyone has converted and MF04, please report what worked or didn't work for you.

EDIT: Stock isolation ring is focused.  Centering the emitter was all that was needed.

ZozzV6
ZozzV6's picture
Offline
Last seen: 2 days 3 hours ago
Joined: 03/24/2016 - 12:19
Posts: 2158
Location: Near to my soldering iron.

^^^^
Measure it from at least 15-20m. the reflector/led size ratio is huge so need big distance for measurement.

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam
led4power wrote:

CSLNM1.TG – throw king in 1mm2 class (let’s call it 1mm2 white flat)


CSLPM1.TG – throw king in 2mm2 class (let’s call it 2mm2 white flat)


1mm2 one is “absolute” throw king if you compare cd/mm2, so if you want max. throw ->1mm2 white flat.


As usual,smaller die LEDs can be overdriven harder, 1mm2 white flat has peak output at ~5.5-5.75Amps, 2mm2 one has peak at ~8.5Amps, obviously 1mm2 can take more power per mm2.


BLF member luminarium can tell more about real life experience of both LEDs,since he built few lights with both LEDs.




I checked the PM1 (so with the larger rectangular die) in my Lumintop mini-GT. Previously it had a dedomed XP-G2 S4 2B that throwed 235 kcd. With the PM1 (well focussed, perfect beam) I had to remove all bypasses and use a not fully charged GA cell to avoid the purple tint, and I got 238 kcd max, even still 235 kcd with the GA cell at 3.7 V.

So no throw gains over the dedomed XP-G2 S4 2B (well, it does maintain throw much better) but the tint is better without the green hue.

But still the PM1 will have to go because the mini-GT driver does not like the extreme low voltage PM1, during the complete low side of the ramp the led does not light up at all, not just on the 7135 but also into the FET region of the ramp (as reported by the blinking of the switch light). So well into the FET region I first get light but very low at first, I measured 12 lumen, so that is halfway the ramp, from there going up.

(Edit: after later swapping to dedomed XP-G2 again, the problem of the led not lighting up at the low side of the ramp persisted, so I have a driver problem Sad ).

I did not measure amps btw, it was easy to spot by the led tint when the current got too high.

I will put a dedomed XP-G2 S3 3D led in the mini-GT next, both good tint and throw.

led4power
led4power's picture
Offline
Last seen: 46 min 40 sec ago
Joined: 12/29/2012 - 09:48
Posts: 1098
Location: Croatia,EU

Even without bypasses and not fully charged GA you could still be over point of max. brightness with this LED (Vf at 8.5A <3.3V), so conclusion that there are "no throw gains over the dedomed XP-G2 S4 2B" is incomplete at best.

When tested with bench supply, this LED works like any other, light up at 1mA and much lower that that.





ZozzV6
ZozzV6's picture
Offline
Last seen: 2 days 3 hours ago
Joined: 03/24/2016 - 12:19
Posts: 2158
Location: Near to my soldering iron.

I have no problem with GT mini driver. Have moon mode normally.

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

That is a weird result that I get then, I assumed that the GT driver responded badly to the low voltage of the PM1 but if other people find normal driver behaviour there must be something specific different in my case, I would not know what.

@led4power, with the GA cell still at 3.8 V resting voltage (3.7 V was when the cell was not yet recovered from high drain), I measure 6.65 A with the clamp meter, with tail off. So with tail on (unbypassed spring) it will be a bit less. The tint was normal (no hint of purple) and I promise that I used not too much solder this time to reflow the led Wink

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

I’m usually not that much into cool tints, but at max the tint is a really good cool white btw, 69CRI, 6800K and slightly under the BBL.

led4power
led4power's picture
Offline
Last seen: 46 min 40 sec ago
Joined: 12/29/2012 - 09:48
Posts: 1098
Location: Croatia,EU

djozz wrote:
@led4power, with the GA cell still at 3.8 V resting voltage (3.7 V was when the cell was not yet recovered from high drain), I measure 6.65 A with the clamp meter, with tail off. So with tail on (unbypassed spring) it will be a bit less. The tint was normal (no hint of purple) and I promise that I used not too much solder this time to reflow the led ;)

In that case LED is underdriven (maybe 4-5Amps), so kcd numbers similar to XPG2 S4 make sense, but in that case it's strange to hear from you ""no throw gains over the dedomed XP-G2 S4 2B", when you know you didn't drive this LEDs close to its maximum (unlike XPG2 S4).

djozz
djozz's picture
Offline
Last seen: 33 min 9 sec ago
Joined: 09/07/2012 - 17:04
Posts: 14766
Location: Amsterdam

led4power wrote:

djozz wrote:
@led4power, with the GA cell still at 3.8 V resting voltage (3.7 V was when the cell was not yet recovered from high drain), I measure 6.65 A with the clamp meter, with tail off. So with tail on (unbypassed spring) it will be a bit less. The tint was normal (no hint of purple) and I promise that I used not too much solder this time to reflow the led Wink

In that case LED is underdriven (maybe 4-5Amps), so kcd numbers similar to XPG2 S4 make sense, but in that case it’s strange to hear from you ““no throw gains over the dedomed XP-G2 S4 2B”, when you know you didn’t drive this LEDs close to its maximum (unlike XPG2 S4).


I think with tail on it is still closer to 6A than 4-5 amps, but in any case I did not make a general claim about this led but it was about what it did with my mini-GT compared to the led that was in there before, in the way that I built it. Still, I’m curious what other people find about the PM1.

Ok, I went ‘back’ to a dedomed XP-G2 S4 3D (as claimed by intl-outdoor) and applied all the bypasses again and what is extremely annoying is that the driver still shows the problem of not lighting the led up at the low side of the ramp. So this is not a problem caused by the PM1 (at least it is not gone when swapping the PM1 again). I will have to beg Neal for a new driver again (the mini-GT has not been a succes for me thusfar).
The tint is now yellowish but pretty ok (no green although well above the BBL, duv +0.012, 4100K) and I measure 225 kcd.

The_Driver
The_Driver's picture
Offline
Last seen: 2 hours 16 min ago
Joined: 10/20/2016 - 05:51
Posts: 1338
Location: Germany

A duv of 0.012 is not too bad ;).

ZozzV6
ZozzV6's picture
Offline
Last seen: 2 days 3 hours ago
Joined: 03/24/2016 - 12:19
Posts: 2158
Location: Near to my soldering iron.

Maybe the 7135 died.
