Yeah, 0,0003” nickel is durable.

However, at 7 microns, that means the part must have spent ages in the bath to form such a layer without electricity.

My very own high current Beryllium Copper springs: http://budgetlightforum.com/node/64047
Liitokala Aliexpress Stores Battery Fraud: http://budgetlightforum.com/node/60547

Firelight2
Firelight2's picture
Offline
Last seen: 7 hours 8 min ago
Joined: 04/08/2011 - 15:17
Posts: 3398
Location: California

I think I’d rather just get a Titanium FW3A. That way if I drop it I don’t have to worry about nickel plating coming off.

Umpi2000
Online
Last seen: 10 min 31 sec ago
Joined: 03/15/2017 - 08:06
Posts: 191
Location: Durban, South Africa

Man I asked the other night about converting to Quad Big Smile

JaredM
JaredM's picture
Offline
Last seen: 15 hours 51 min ago
Joined: 10/31/2011 - 13:33
Posts: 544
Location: Pittsburgh, Pennsylvania
Umpi2000 wrote:
Man I asked the other night about converting to Quad Big Smile

It’s very close to being able to fit. If I find a way to very slightly reduce the outer diameter of the optic (without damaging it), eliminating the glass lens and adding a spacer under the MCPCB could be enough.

..

Maybe if I sacrifice one quad optic and press it into some epoxy puddy that’s inside a cardboard tube, remove the optic, and let it cure maybe I can chuck it in a lathe and take ~0.5mm off the radius. I’ll try that I guess..

KawiBoy1428
KawiBoy1428's picture
Online
Last seen: 8 min 41 sec ago
Joined: 04/11/2014 - 18:05
Posts: 3483
Location: The Motor City
JaredM wrote:
Umpi2000 wrote:
Man I asked the other night about converting to Quad Big Smile

It’s very close to being able to fit. If I find a way to very slightly reduce the outer diameter of the optic (without damaging it), eliminating the glass lens and adding a spacer under the MCPCB could be enough.

..

Maybe if I sacrifice one quad optic and press it into some epoxy puddy that’s inside a cardboard tube, remove the optic, and let it cure maybe I can chuck it in a lathe and take ~0.5mm off the radius. I’ll try that I guess..


Do you have a Live Center for your Lathe? I cut a 20mm pocket in a piece of round stock to fit the quad board snugly, popped the optic on and run the Live Center up to the optic with a piece of thick rubber between the optic and live center, locked the tail stock and ran the center up to hold everything together,with just enough force to hold while turning the chuck, then locked the tail stock quill. No crazy RPM and be cool with the tool pressure, that plastic cuts very easy.

KB1428 “Live Life WOT”

JaredM
JaredM's picture
Offline
Last seen: 15 hours 51 min ago
Joined: 10/31/2011 - 13:33
Posts: 544
Location: Pittsburgh, Pennsylvania

Great tip KawiBoy. Thanks!

I don’t have a lathe of my own but I have access to them at work. We do have live centers. I’ll try this tomorrow maybe. I was initially concerned about the torque/shear applied to the legs would break them. Beer

Cheers

M3CSL
M3CSL's picture
Offline
Last seen: 6 hours 48 min ago
Joined: 05/02/2019 - 05:34
Posts: 197

JaredM wrote:
It’s very close to being able to fit. If I find a way to very slightly reduce the outer diameter of the optic (without damaging it), eliminating the glass lens and adding a spacer under the MCPCB could be enough.

(…) let it cure maybe I can chuck it in a lathe and take ~0.5mm off the radius (..)

If the diameter only has to be reduced by .5mm I am a bit relieved, thought it would be a tighter fit and 2mm had to go.

But why would the lens have to go and/or the addition of a spacer? According to Carclo specs the triple and quad have the exact same height. Or is there a difference in quad/triple MCPCBs? I am at work and can’t measure at the moment; my memory tells me they are both 1.5mm (I could be wrong)?

Thanks.

Convoy S2+ 219b triple, Astrolux FT02, Maglite 3D, Solarforce L2t

Henk4U2
Henk4U2's picture
Offline
Last seen: 58 min 49 sec ago
Joined: 02/13/2014 - 17:52
Posts: 2570
Location: The heart of the Netherlands (GMT+1)

For those without access to a lathe. I draw a circle with a fine felt tip pen and a drawing template. Remove the material outside the circle with a bench grinder (big wheel, fine grain). Put a light on the brim of your baseball cap for better vision. Firm grip but low pressure does the trick with plastics.

You are a flashaholic if you are forced to come out of the closet, to make room for more flashlights.

Firelight2
Firelight2's picture
Offline
Last seen: 7 hours 8 min ago
Joined: 04/08/2011 - 15:17
Posts: 3398
Location: California

Or you can do it the way I’d do it:

Sit down at your desk with a handfile and some music and start grinding. Shouldn’t take more than an hour to grind the star and optic to a suitable size.

It’s not very efficient or fast, but it is cheap and easy. I’ve ground down many stars over the years by hand this way and never had any trouble keeping them centered.

Oli
Offline
Last seen: 1 week 6 days ago
Joined: 08/03/2018 - 21:03
Posts: 16
Location: United States

https://www.ebay.com/itm/Dalex-2-Way-Mount-Adjustable-Size-4-25-4-75-Wid.... Vertical or HORIZONTAL nylon belt pouch. This should be a perfect size for this light. It looks like the label is simply sewed on and should come off easily. Not many left. Raine Inc makes a “deluxe knife sheath” in a few different sizes and one of them might work also but there are not many other choices for horizontal carry. Light and pouch enroute.

cabfrank
Offline
Last seen: 9 hours 58 sec ago
Joined: 11/19/2010 - 17:25
Posts: 2703
Location: healdsburg, california usa earth
Firelight2 wrote:
I notice Vinh has his FW3Avn thread up on CPF. Looks like he’s modified them with Oslon white flat and Nichia 219B. And he also made one into a quad using a modified Carclo quad optic.

Can you please link that thread? Thanks.

cabfrank
Offline
Last seen: 9 hours 58 sec ago
Joined: 11/19/2010 - 17:25
Posts: 2703
Location: healdsburg, california usa earth

Found it.

ToyKeeper
ToyKeeper's picture
Offline
Last seen: 7 hours 52 min ago
Joined: 01/12/2013 - 14:40
Posts: 9292
Location: (469219) 2016 HO3
KawiBoy1428 wrote:
it is HERs now…the Sinner Triple Ti sits on the dresser …“the Lightning mode is amazing” should of never showed HER that…. Sad

You know what you have to do now, right?

Get her a matching diffuser cap, put the light in candle mode, and prepare her a nice hot bath. Innocent

teacher
teacher's picture
Online
Last seen: 14 min 19 sec ago
Joined: 02/23/2016 - 19:04
Posts: 8753
Location: NE & SW Alabama

cabfrank wrote:
Found it.
I still can’t find it. Facepalm . Link please… Smile

You never know how a horse will pull until you hook him up to a heavy load./"Bear" Bryant

 .................................. "Slow is Smooth, Smooth is Fast" ...................................

       Texas Lumens Flashlights / M4D M4X Deals : sign up - save $$$$

         Rudeness Level _ mΩ _ {width:70%} _ LightWiki _ LED Tint Chart

      Xlamp size chart _ BatteryU _ Flashaholic? Need Professional Help???            TheOriginal _ TAB _ LightSearch _ BatterySearch _ 14500's _ DiCal





cabfrank
Offline
Last seen: 9 hours 58 sec ago
Joined: 11/19/2010 - 17:25
Posts: 2703
Location: healdsburg, california usa earth
Firelight2
Firelight2's picture
Offline
Last seen: 7 hours 8 min ago
Joined: 04/08/2011 - 15:17
Posts: 3398
Location: California
BurningPlayd0h
BurningPlayd0h's picture
Offline
Last seen: 2 hours 5 min ago
Joined: 06/22/2018 - 02:16
Posts: 446
Location: MN

teacher wrote:
cabfrank wrote:
Found it.
I still can’t find it. Facepalm . Link please… Smile

https://www.candlepowerforums.com/vb/showthread.php?458653-Lumintop-FW3A...
teacher
teacher's picture
Online
Last seen: 14 min 19 sec ago
Joined: 02/23/2016 - 19:04
Posts: 8753
Location: NE & SW Alabama

/\ Thanks for the link gentlemen…. Thumbs Up

You never know how a horse will pull until you hook him up to a heavy load./"Bear" Bryant

 .................................. "Slow is Smooth, Smooth is Fast" ...................................

       Texas Lumens Flashlights / M4D M4X Deals : sign up - save $$$$

         Rudeness Level _ mΩ _ {width:70%} _ LightWiki _ LED Tint Chart

      Xlamp size chart _ BatteryU _ Flashaholic? Need Professional Help???            TheOriginal _ TAB _ LightSearch _ BatterySearch _ 14500's _ DiCal





KawiBoy1428
KawiBoy1428's picture
Online
Last seen: 8 min 41 sec ago
Joined: 04/11/2014 - 18:05
Posts: 3483
Location: The Motor City

FW3A Quad in a word…Yuck!

. Sick

KB1428 “Live Life WOT”

cabfrank
Offline
Last seen: 9 hours 58 sec ago
Joined: 11/19/2010 - 17:25
Posts: 2703
Location: healdsburg, california usa earth

Why yuck?

Bob_McBob
Offline
Last seen: 14 hours 58 min ago
Joined: 08/14/2016 - 04:53
Posts: 442
Location: Canada

I received my FW3A shipment and stuck 219Bs in one of them right away. Next up is sliced dog farts (5000K LH351D). The stock XP-L HI 3D is pretty ugly (Duv 0.0035 or worse on practical levels), but it’s much nicer with sw45k Smile

Full measurements on Reddit:

https://www.reddit.com/r/flashlight/comments/bmpt0m/nld_blflumintop_fw3a...

KawiBoy1428
KawiBoy1428's picture
Online
Last seen: 8 min 41 sec ago
Joined: 04/11/2014 - 18:05
Posts: 3483
Location: The Motor City

cabfrank wrote:
Why yuck?

Alot is cut off/out at the bezel, the beam is kinda Funky, outside on Turbo not too bad for the few seconds you can use it…. and I mean seconds…. I prefer the triple….

KB1428 “Live Life WOT”

cabfrank
Offline
Last seen: 9 hours 58 sec ago
Joined: 11/19/2010 - 17:25
Posts: 2703
Location: healdsburg, california usa earth

Fair enough. Still impressive skills though.

KawiBoy1428
KawiBoy1428's picture
Online
Last seen: 8 min 41 sec ago
Joined: 04/11/2014 - 18:05
Posts: 3483
Location: The Motor City

cabfrank wrote:
Fair enough. Still impressive skills though.

Thanks!

. Here is the Funky Square-ish Beam it produces… Big Smile

KB1428 “Live Life WOT”

cabfrank
Offline
Last seen: 9 hours 58 sec ago
Joined: 11/19/2010 - 17:25
Posts: 2703
Location: healdsburg, california usa earth

Yeah. Are you going to change it back, or try other emitters?

Tally-ho
Tally-ho's picture
Offline
Last seen: 10 hours 35 min ago
Joined: 07/23/2011 - 04:15
Posts: 1005
Location: France

Bob_McBob wrote:
The stock XP-L HI 3D is pretty ugly (Duv 0.0035 or worse on practical levels)


Oh my gosh !
CRI70, not a good Duv, desaturates most colors (over-saturates green-yellowish), lot of hue shifts and colors fidelity sucks.

I only ordered a Convoy desert S2+ with XP-L HI 3A and was done with XP-L HI. How could people always asking for this expensive and ugly thing for the sake of a tint and a bit longer but ephemeral turbo ?

Umpi2000
Online
Last seen: 10 min 31 sec ago
Joined: 03/15/2017 - 08:06
Posts: 191
Location: Durban, South Africa

KawiBoy1428 wrote:
cabfrank wrote:
Fair enough. Still impressive skills though.

Thanks!

. Here is the Funky Square-ish Beam it produces… Big Smile !{width:80%}https://i.postimg.cc/hjmNQXg0/IMG-0433.jpg!

Quick and nice work still KB! Which 106xx optic did you use?

iamlucky13
Offline
Last seen: 12 hours 4 min ago
Joined: 06/22/2018 - 09:18
Posts: 436
Location: USA
Bob_McBob wrote:
I received my FW3A shipment and stuck 219Bs in one of them right away. Next up is sliced dog farts (5000K LH351D). The stock XP-L HI 3D is pretty ugly (Duv 0.0035 or worse on practical levels), but it’s much nicer with sw45k Smile

I’ll be curious to read the report on the sliced DA0GF4RTs. I’m guessing not quite as nice looking as the 219B, about the same cd/lumen, but higher max output.

M3CSL
M3CSL's picture
Offline
Last seen: 6 hours 48 min ago
Joined: 05/02/2019 - 05:34
Posts: 197

Thank you so much for the quad beam, looks funky indeed.

Convoy S2+ 219b triple, Astrolux FT02, Maglite 3D, Solarforce L2t

steel_1024
steel_1024's picture
Offline
Last seen: 16 min ago
Joined: 10/17/2016 - 14:06
Posts: 481
Location: Taiwan

Thermal paste is not applied evenly.
if it is possible…
Please reapply the thermal paste.

Driver

Reflash newest firmware.
anduril.2019-04-24.fw3a-219.hex(For Nichia 219B_V1)
anduril.2019-04-24.fw3a.hex

CREE XP-L Hi 3D (5000K)

Nichia 219B_V1 4000K R9080

Samsung LH351D 4000K 90CRI

XPL Hi、219B、LH351D

Ramp Ceiling (moment),steel_lumen
XPL Hi:1020
219B:656
LH351D:887

Sorry for my poor english.
