Ended up rerouting everything.  Got rid of almost all the errors.  Don't know how to get rid of the error for the 2 pins that happen to be directly on top of each other.  I put via's on the contact pads to electrically connect them.  Not sure if I need to fix the errors.  Gonna post a question in the Eagle thread.  Here is the latest:

Mike C
Mike C's picture
Offline
Last seen: 1 week 23 hours ago
Joined: 01/22/2014 - 08:03
Posts: 2585
Location: Sweden

Those yellow crosses over the vias are not desirable, at least not when I do my boards. They might not really matter, but they are an error indication from Eagle. If you have the signals routed correctly, these shouldn’t show up.

Regarding design rule checks, many people don’t do them at all. They do generate a lot of errors that are of no real concern, like the overlap in your last post. It’s OK to put a via directly under a component leg like that, but eagle flags them as an overlap error. As long as the signal is the same it’s no problem. Another error of no real concern is when vias of the signal are close but not under a leg. You might get a clearance error. Once again, if the signal is the same it is of no concern. Stop mask errors are also no concern. You get them when there is white print from a component that crosses exposed copper, and OSH Park (I guess most other manufacturers too) don’t care, they do not put white print over exposed copper.

Personally I always do design rule checks. I do them once I’m close to the end of my design and I go through each error. The errors I don’t care about I approve, and then they don’t show up in the list any more unless you move the component or trace that caused it. It doesn’t take much time to analyze and approve them, and by far beats the headache of having missed something. I’ve been saved a couple of times when the DRC found sloppy mistakes I didn’t notice myself.

Download the manufacturers DRC files. Eagle’s default design rules are not the same as OSH Park, like drill sizes for vias for example. If you’re going to do a DRC you might as well do it using the design rules from the PCB manufacturer you will be using.

I also have downloaded OSH Park CAM files for gerber generation. If I remember correctly, there are different CAM files for different versions of Eagle. There are newer CAM files for Eagle v7.2.0. I don’t use the ones Mattaus provided in the Eagle tutorial thread as I use Eagle 7.2.0.

ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

Wow, lots of excellent info there.  Thank you.  It all sounds good to me.  I will follow it.

Yeah, I eventually figured out the X's were bad.  I was pre-instaling the via's, but only  on one side.  I eventually read about using the shift, mouse click function.  Then did it on both sides and the error would go away.

ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

Finally got the adapter board designed and ordered.  It took me a lot of time.  I struggled with learning Eagle and building the parts.  Parts represent the MCU’s.  I could not find any already made as I don’t know what MCU’s these are.  I ended up having to manually make a mirror image of the part the represents the HD MCU and then use the Eagle Mirror command to get it on the bottom side of the board.   When Eagle did that, it put the pins in the proper spots (not mirror image).  Anyway, I spent a ton of time on the whole process, but I can now design my own custom pcb's.  That is going to be really handy for me since I tend to swap MCU's in drivers.  Special thanks to Halo..., Mike C, and wight for the tips they provided.

I'll report back on weather they work when boards come in.

Here is an idea of what they have under the solder mask.

Top and bottom combined view:

Top side only:

Bottom side only:

Now, lets hope they actually work.

Mike C
Mike C's picture
Offline
Last seen: 1 week 23 hours ago
Joined: 01/22/2014 - 08:03
Posts: 2585
Location: Sweden

Looks good!

A tip about library parts, especially for MCUs (maybe a bit late). You don’t have to know the exact MCU to get a library file for the footprint, you just need to know the case. The one above looks like SOIC14. So to get one create an account at Newark Element14, find a SOIC14 processor (like the ATtiny24) and there is a CadSoft_EAGLE link under the product information:
http://www.newark.com/atmel/attiny24a-ssu/microcontroller-mcu-8-bit-atti...

There is a readme.txt in it describing how you make a library part from it.

MRsDNF
MRsDNF's picture
Offline
Last seen: 3 months 3 weeks ago
Joined: 12/22/2011 - 21:18
Posts: 13473
Location: A light beam away from the missus in the land of Aus.

What an effort guys. You gotta love the help from others here and glad a new road is ahead of you ImA4Wheelr.



djozz quotes, "it came with chinese lettering that is chinese to me".

                      "My man mousehole needs one too"

old4570 said "I'm not an expert , so don't suffer from any such technical restrictions".

Old-Lumens. Highly admired and cherished member of Budget Light Forum. 11.5.2011 - 20.12.16. RIP.



bobale
Offline
Last seen: 9 months 1 week ago
Joined: 10/09/2012 - 16:09
Posts: 5
Location: Serbia

Guys, any news regarding this mod?

I’m thinking about buying this lamp, and I really like it, apart from stock modes, obviously.

garrybunk
garrybunk's picture
Offline
Last seen: 4 days 18 hours ago
Joined: 10/31/2011 - 09:25
Posts: 6099
Location: Johnstown, PA

Well I'll let ImA speak up, but from our PM's I've gathered that this has been a very difficult mod which has been fighting him all the way! The KD driver is nearly perfect (MTBR guys love it), but it's not a direct fit into this light. ImA has been a real trooper through the struggle though! I'd have probably given up a long time ago! I do believe he's very close to having it fully functional.



-Garry

My Bike Lights Thread, Optics (TIR) Comparison Beamshots, Diffusion Techniques

, MTBR’s Lights & Night Riding Forum
NOTE: Now hosting my photos from my Google account. Post up if you can’t see them. Older photos hosted on Photobucket or Flickr may disappear (PM me if you want access to them).
ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

Welcome to the forum bobale.  I apologize for not posting updates.  I came online to post an update to Garry when I noted this thread has activity.  Much has been going on with this light, but almost every step forward has resulted in complications and set backs.  Tonight was yet another frustrating night and I have to admit that I am near my wits end with this light.

If you haven't purchased this light yet, I recommend you don't purchase one if your intention is to modify it. The driver is not mod friendly at all.  It seems to have been built to barely handle the current it delivers stock.  It is also 3 dimensional which creates all kinds of complications with reflowing and even just soldering components.  If I do successfully mod this light, I don't think anyone should try to replicate it.  I was entertaining modding another one of these for myself but I have decided against that a ways back.  Besides the driver, the light itself is very compact and has very little "elbow" room for heat sinking.  For that reason, I think a custom made copper heat sinking solution is the only real way to extract the heat to the small exterior of the light that will quickly overheat if not in motion.  The tight space appears prohibit piggy backing a different buck driver.

Sorry for all this bad news.  If you have purchased the light, I will gladly try to coach you through modding it.  Just understand that it's a risky ordeal with a good chance for failure.  I suggest keeping this one stock.

EDIT: The above warning has been added to the OP.

bobale
Offline
Last seen: 9 months 1 week ago
Joined: 10/09/2012 - 16:09
Posts: 5
Location: Serbia

Thanks for all the info. I haven’t bought the lamp yet, but I’ve ordered one for my MTB riding friend. He doesn’t mind the stupid modes, but I do and that’s why I’ve wanted to mod it in the first place.

I’ve experimented with few different handlebar lights, and I really like this flood-throw combination in one lamp. But, if this HD-016 thing doesn’t work out, I still have my two MJ808E clones, one with regular glass lens, and one with Action-LED wide angle lens, so I guess this combination can also work good offroad (not yet tested on a trail).

garrybunk
garrybunk's picture
Offline
Last seen: 4 days 18 hours ago
Joined: 10/31/2011 - 09:25
Posts: 6099
Location: Johnstown, PA

If you're not already familiar with it, there was a recent group buy on the "real" Yinding (Gemini Duo clone) over at mtbr.com which is available in neutral white or cool white.  The KD driver fits and it also accepts a range of different optics. Has good thermal contact to the emitter board, but not much mass to it.  There's also a Nitefighter BT40S on ebay which is a 4x XP-G2 in neutral white. I just picked up the lighthead only "on sale".  Some "good" inexpensive options for you, though neither has the flood this one has.

-Garry

My Bike Lights Thread, Optics (TIR) Comparison Beamshots, Diffusion Techniques

, MTBR’s Lights & Night Riding Forum
NOTE: Now hosting my photos from my Google account. Post up if you can’t see them. Older photos hosted on Photobucket or Flickr may disappear (PM me if you want access to them).
ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

Part of the problem may be that this is a very ambitious mod.  We are trying to graft on another 14 pin MCU that is vastly different.  We are also trying to keep all the features such as indicator lights, voltage monitoring/protection and thermal monitoring/protection.  This has forced me to modify circuits by cutting traces, adding wires, and such.   Oddly enough, the extra features appear to be working fine (haven't thoroughly yet).  It's the buck drivers that are giving me hell.  I think the FET's have been overheating and frying.  They are very small FET's and have very thin traces connecting to them.  So any heat that generates, stays in the FET.  I've tried harder FET's without success.  I'm now trying larger off-board FET's but am having other issues now.   The driver board that has the 2 buck drivers is approaching a state irreparable deterioration due to all the reflows and soldering.

If you end up finding your self wanting to mod one of these light, I think you can successfully do so if you go for less functionality and don't try to increase current to the emitters.

It's also possible that I have damaged something that is causing all this grief.  I'm still trying to figure out what is wrong.  If/when I find out, I will report it.

bobale
Offline
Last seen: 9 months 1 week ago
Joined: 10/09/2012 - 16:09
Posts: 5
Location: Serbia

I don’t really care for thermal protection as I always dim down my light when I slow down or stop. I planned on leaving stock MCU for voltage monitoring, as I can’t really be bothered with voltage dividers and endlessly tweaking the circuit to give me correct readings. If heat is an issue, I don’t mind taking the driver board out of the lamp.

ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

Got a question for the thermal protection dabblers out there.  First a very quick high level status.  Last below paragraph has question.

This project has taken a lot of turns  At this point, very little of the original light is left.  The light is a stubborn bugger and has kicked my butt a few times along the way.  We changed direction of the build several times as we thought of better approaches and to resolve problems.  Much time was waiting for parts from China and I am also to blame for the slow pace of the build.  In the end, we had to toss the buck driver part of the light as it continually had component failures.  In my amateur opinion, the buck driver part of this light has 2 major flaws.  One, too small of components and two, no thermal path to heat sinking.

The good news is that the linear driver replacing it will be much more efficient and provide longer effective run time.  Less regulated run time, but more useful run time.   Additionally, the light should have all the functionality Garry wanted.  It will also have copper innards from head to toe.  Not something Garry asked for, but I could not control myself.

So here's the thermal protection info and question.  The thermal protection kicks in around 130F (54C).  This seems way too low.  It steps down output by going to Low mode.  As soon as the driver cools down to around 115 - 130 F, the light automatically returns to Medium or High mode (what ever mode it was in before step down).  It's a pretty drastic step down, but it is what it is.  My question is.  What is the maximum temperature should I tune the Thermal Protection Circuit to but still have a little safety margin on not frying any components?

ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

^ I guess the more important question is what is the maximum temperature Garry would like the light to reach before thermal protection kicks in.

I'm thinking that all the components can tolerate a higher temperature than that, but I would still like to hear any input members may have for the question I have in the above post.

I'm glad that the AMC7135's have built in thermal protection that steps down to 250mA because that will give a nice smaller level step down before the MCU kicks down all the way to Low Mode.  Well, I guess that will depend on what temp Garry wants the MCU set at.  I don't recall the temp that the 7135's step down.  I think it's a pretty high temp though.

If any of you have any recommendations for Garry, I, and I imagine he, will appreciate your input.  Keep in mind that this light will be handle bar mounted.  So it seems to me a higher temp than what can be tolerated in hand would be fine.

Mike C
Mike C's picture
Offline
Last seen: 1 week 23 hours ago
Joined: 01/22/2014 - 08:03
Posts: 2585
Location: Sweden

I haven’t gotten around to temperature monitoring in my headlight project yet, but my thoughts are that I obviously don’t want to exceed the MCU’s operating temperature as it’s the MCU’s internal temp sensor I will be using (ATtiny84V). Having it ramp down at 150c if the MCU is rated to 125c is useless, unless you are counting on the MCU being able to fully operate at 150c. Also worth considering is when the temp sensor reaches a certain temp, how hot is the rest of the stuff? Is the temp sensor directly in contact with the host or is it taking the temp of the air inside the host?

If the goal is to be able to touch the light without discomfort, then I’d just do some trial and error as it is probably lower than what any of the components are rated for. If the goal is to push this light to the limits of what the components can handle, then I guess you’d have to figure out the weakest link and check how hot that link is at a given reading from the sensor.

ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

Thank Mike C.  My guess is Garry will want a much, much lower step down than 125c or 150c (257f - 302f).  Having something that hot, even if mounted to the handlebar, will pose a safety issue to anyone around that might want to casually touch the light.

There will be a little lag on the sensor reading, but not a lot.  The light is very compact and copper will conduct the overall temp of the host to a spot close to the sensor.  The sensor will have some thermal compound connecting it to the copper/body.

I agree, any temp Garry decides on will be much lower than even the weakest component can handle.


EDIT:

Tried to get more accurate readings on when Thermal Step Down kicks in and when it kicks off.  It's tough because I'm using an IR meter and the driver is small.  Best I can tell, thermal step down kicks in around 140F (maybe a few degrees higher).  Step down kicks off (meaning light resumes normal output) around 120F.  Now I'm starting to think the stock set up is what I recommend sticking with.  The light itself will be a little hotter before the sensor reaches 140F.  That's starting to get hot enough to be a safety concern.  Enough to give someone a burn, but they should react fast enough to not get serious burn.

My biggest concern is a different safety issue.  That is the light steps all the way down to Low Mode while the rider is in treacherous terrain.  The higher the thermal kick down point, the less thermal kick downs will occur, but the burn risk then increases.

If the rider had a helmet light on, thermal kick down won't be as big a deal.  Maybe slow down a little and then switch to Medium Mode after thermal step down kicks off.

I reprogrammed Low Mode to be more than 25mA, but the driver still steps down to 25mA when thermal step down kicks in.

Mike C
Mike C's picture
Offline
Last seen: 1 week 23 hours ago
Joined: 01/22/2014 - 08:03
Posts: 2585
Location: Sweden

ImA4Wheelr wrote:
My biggest concern is a different safety issue.  That is the light steps all the way down to Low Mode while the rider is in treacherous terrain.  The higher the thermal kick down point, the less thermal kick downs will occur, but the burn risk then increases.

If the rider had a helmet light on, thermal kick down won’t be as big a deal.  Maybe slow down a little and then switch to Medium Mode after thermal step down kicks off.

I reprogrammed Low Mode to be more than 25mA, but the driver still steps down to 25mA when thermal step down kicks in.


I haven’t really been following what you can and can not do with this driver. What kind of control do you have over the temperature monitoring? When I get around to temp monitoring on my project I was thinking about a hidden temperature controlled mode. Instead of running on highest until too hot and stepping down to low I was thinking about running it on the highest it can run for a given temperature, lowering the output gradually as the temperature rises towards the threshold.

I have no idea how practical this will be until I try it out, but maybe something like this would suite a bike light better than going from high straight to low without warning, but it seems that this would be difficult on the driver you have as it appears to go to 25mA despite the low mode is above that.

ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

^ Our options on this light are limited because we can not reprogram the unknown 14 pin MCU.  The MCU is from the KD driver for the ________ (forgot model) bike light.  So all I can do is tune the voltage divider that the thermistor is part of.

In your case, you what ever options you can imagine and program.  I think many folks (Including me) will be interested in your work on that front.

Mike C
Mike C's picture
Offline
Last seen: 1 week 23 hours ago
Joined: 01/22/2014 - 08:03
Posts: 2585
Location: Sweden

ImA4Wheelr wrote:

^ Our options on this light are limited because we can not reprogram the unknown 14 pin MCU.  The MCU is from the KD driver for the ________ (forgot model) bike light.  So all I can do is tune the voltage divider that the thermistor is part of.


I see. Yeah, your options are very limited in that case. As mentioned I haven’t been following to the full. I thought that as you where going to piggy-back a 13A that you might have had more options.

ImA4Wheelr wrote:

In your case, you what ever options you can imagine and program.  I think many folks (Including me) will be interested in your work on that front.


I’ll make a thread about my project when it reaches prototype testing stage. Right now I only have the driver board assembled. I have a host to test it in once I get the firmware ready for field testing, but the programming is taking it’s time. It’s a dual LED type like this project, but with both a mechanical and electronic switch.
garrybunk
garrybunk's picture
Offline
Last seen: 4 days 18 hours ago
Joined: 10/31/2011 - 09:25
Posts: 6099
Location: Johnstown, PA

For reference, the stock Yinding light has been measured with a case temp at 150 degrees at thermal stepdown.  I can concur that my Yinding the other night was pretty darn hot when I ran it on high for about 5 minutes during a downhill descent.  I was fine with the case being that hot (as far as potentially burning myself goes).  I would likely also add an aluminum GoPro mount (seen in that thread linked above) to another aluminum GoPro handlebar mount (like these) and have it attached to my aluminum handlebar.

EDIT - Here is a link to the KD driver being partially used in this build.  The light it is intended for has been referred to as the "KD2".

-Garry

My Bike Lights Thread, Optics (TIR) Comparison Beamshots, Diffusion Techniques

, MTBR’s Lights & Night Riding Forum
NOTE: Now hosting my photos from my Google account. Post up if you can’t see them. Older photos hosted on Photobucket or Flickr may disappear (PM me if you want access to them).
ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

^ OK.  Unless I hear otherwise from you, we'll stick with the stock configuration on themal step down.  I image the case will likely hit 150F since there will be a small time lag before the heat hits the thermistor.

So, all the ingredients are on hand and adjustments have been made.   I now need to finish deciding on how mod the driver to accommodate the cable gland for the new cable.  Once that is down, it's assembly and some follow-up testing.  I redo the OP with the complete build once the light if finished.

Mike C wrote:I see.

Yeah, your options are very limited in that case. As mentioned I haven’t been following to the full. I thought that as you where going to piggy-back a 13A that you might have had more options.

Yeah we started this project with the Attiny13a, but it had limitations that prevented realizing all the functionality Garry wanted.  Luckily, the KD2 came out with all the functionality Garry wanted.  Garry was able to get KD to sell just the driver.  That put us on the long road to merging the 2 drivers for this light.  The OP is crazy out of date and I will update it as soon as I finish this build.

Look forward to your thread.  You said you will use the Attiny25?  I know it may be a while before you get to that point, but should I order some now so that I can hopefully help with some of the testing?

Mike C
Mike C's picture
Offline
Last seen: 1 week 23 hours ago
Joined: 01/22/2014 - 08:03
Posts: 2585
Location: Sweden

ImA4Wheelr wrote:
Luckily, the KD2 came out with all the functionality Garry wanted. Garry was able to get KD to sell just the driver. That put us on the long road to merging the 2 drivers for this light.

That actually rings a bell… quite sure I did read this some time back.

ImA4Wheelr wrote:
You said you will use the Attiny25?  I know it may be a while before you get to that point, but should I order some now so that I can hopefully help with some of the testing?

In my headlight project I’m using the ATtiny84. It’s 14 pin with the 8K of programming space. I’m using about 5K of that as it is, and have a few more features to put in before I build the prototype light.

For the 8 pin MCUs in other drivers I’m using the ATtiny85 (also 8K of space). It fits on a 13A footprint with a little pin bending. This firmware isn’t really releasable yet, it’s on hold because I’m prioritizing my 84 headlight firmware. I plan to upload a Q-lite compatible version of the 85 firmware to ToyKeeper’s firmware stash when I’m done. As it is now it only works with my own drivers as I use different pins for everything.

ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

The light is finally completed.  I have totally redone the OP to document the final build.  All other mods that were done, but tossed have been removed to reduce the size of the OP.

Mike C
Mike C's picture
Offline
Last seen: 1 week 23 hours ago
Joined: 01/22/2014 - 08:03
Posts: 2585
Location: Sweden

Nice to see it finally done! Lot of nice work there, in particular the copper.

Were you able to have any control over what the light steps down to when thermal protection kicks in?

garrybunk
garrybunk's picture
Offline
Last seen: 4 days 18 hours ago
Joined: 10/31/2011 - 09:25
Posts: 6099
Location: Johnstown, PA

I see you did get beamshots uploaded. Very nice! I can't wait to try it out for myself!

I appreciate all your hard work on this ImA! It looks fantastic!



By the way, I picked up another one for you to mod just like this one, okay? Just kidding! (I wouldn't do that to you.)



Thanks,

-Garry

My Bike Lights Thread, Optics (TIR) Comparison Beamshots, Diffusion Techniques

, MTBR’s Lights & Night Riding Forum
NOTE: Now hosting my photos from my Google account. Post up if you can’t see them. Older photos hosted on Photobucket or Flickr may disappear (PM me if you want access to them).
ImA4Wheelr
Offline
Last seen: 2 months 3 weeks ago
Joined: 02/03/2013 - 14:51
Posts: 7935
Location: SC

^ LOL.  Good one.  I took some "before" beam shots, but I'm trying to make sure I have the right ones.  You take much better beam shots than me (by like 2000 million percent).  Hoping you have some befores and take some afters.  I have to say that I really love the tint of the emitters you provided.  I'm going to order some.  I thought I had that same tint, but mine are slightly different.  That small difference is big though.



Mike C wrote:

. . .

Were you able to have any control over what the light steps down to when thermal protection kicks in?

In the end, I opted to keep the step down temperature at the stock 150 degrees Fahrenheit.  The biggest reason was to reduce the likelihood of step down when Garry is riding because the step down is very drastic (goes down to .26A).  Since the light will be handle bar mounted, it seems like a fairly low safety risk burn wise.  If Garry puts the light on an aluminum mount and aluminum handle bar like he said, I think he will have no stepdowns.  I didn't expect such a big lag (body reaches 166 at kick down), but I think it is a plus for this application.  The aluminum mount will bring down the temp fast.



garrybunk
garrybunk's picture
Offline
Last seen: 4 days 18 hours ago
Joined: 10/31/2011 - 09:25
Posts: 6099
Location: Johnstown, PA

Yes, I will try to get some "after" beamshots in the same locations that I got my "before" shots.  I'll post them up when I get them.

-Garry

My Bike Lights Thread, Optics (TIR) Comparison Beamshots, Diffusion Techniques

, MTBR’s Lights & Night Riding Forum
NOTE: Now hosting my photos from my Google account. Post up if you can’t see them. Older photos hosted on Photobucket or Flickr may disappear (PM me if you want access to them).
garrybunk
garrybunk's picture
Offline
Last seen: 4 days 18 hours ago
Joined: 10/31/2011 - 09:25
Posts: 6099
Location: Johnstown, PA

Got in a short ride on the local rail-trail last night to test the light.  This light rocks!  Huge wide flood with decent throw (throwy head lamp really combines for a killer combo) and with my favorite 5B1 tint!  In use this thing gets hot quick!  While I was riding with it (mostly slow. perhaps 8 to 10mph) it did not kick in.  This was with the simple stock plastic mount (need  to upgrade to aluminum GoPro style soon).

Some pics (description above the photos):

Low (I think it's level #2 on the KD driver as I mistakenly entered program mode and am unsure where I set it back to):

1

Medium (level 7):

2

High (level 10):

1

Stepped back from the bike for a shot to show the full flood on high:

1

Excuse the photos as I was not carrying a tripod and I had my camera mounted on a cheap handlebar mount that had a lot of play in it.  The camera also mounted on an angle due to being on my riser bars so I had to tilt the bike to make the photos appear level Smile

I was NOT using a helmet light (nor wearing a helmet), but while riding I did hold my Convoy M1 XM-L2 T6 4C on my head to simulate and it looked great! Provided all the throw I needed.

Comparison "backyard beamshots" coming in the near future.

-Garry


My Bike Lights Thread, Optics (TIR) Comparison Beamshots, Diffusion Techniques

, MTBR’s Lights & Night Riding Forum
NOTE: Now hosting my photos from my Google account. Post up if you can’t see them. Older photos hosted on Photobucket or Flickr may disappear (PM me if you want access to them).
MRsDNF
MRsDNF's picture
Offline
Last seen: 3 months 3 weeks ago
Joined: 12/22/2011 - 21:18
Posts: 13473
Location: A light beam away from the missus in the land of Aus.

Hats of to you ImA4Wheelr. What an extraordinary amount of effort has gone into this light and it works not that I had any doubts. Smile



djozz quotes, "it came with chinese lettering that is chinese to me".

                      "My man mousehole needs one too"

old4570 said "I'm not an expert , so don't suffer from any such technical restrictions".

Old-Lumens. Highly admired and cherished member of Budget Light Forum. 11.5.2011 - 20.12.16. RIP.



Pages
