Calculate PWM_TOPS

Flashlight Modding and DIY Parts
1

We can use level_calc.py to calculate PWM#_LEVELS.
How do we calculate PWM_TOPS?

2

By using level_calc.py. :slight_smile: For example:

level_calc.py 7.01 2 149 7135 3 0.5 125 FET 1 10 1200 --pwm dyn:63:2048:255

The --pwm dyn:… option defines the number of dynamic steps, the maximum and the minimum value.

1 Thank
3

I’m running level_calc.py on my Android phone.
I guess I need to use my laptop to enter those parameters.

Thanks!

4

0dVNyc0
0dVNyc01280×720 100 KB

Maybe few people including Toykeeper know how to use it.

1 Thank
5

How did you decide on 7.01, 63 and 2048?

6

7.01 – by feeling.
63 – by feeling.
2048 – by feeling.

It’s a lot of trial and error, observing the response of the driver and calculating the effective frequency and minimum on-time (a too short on-time might result in highly non-linear response of the driver, depending on the design). There are just a few constraints like thermal regulation must never enter the PFM region.

1 Thank
7

Thanks again!

8

I don’t quite understand what PWM_TOPS is. I understand PWM#_LEVELS but what does PWM_TOPS represent?

9

It’s something to do with Dynamic PWM but I’m not really sure.
I figured out how to use level_calc with the help of sammy and decided i don’t need to know.

2 Thanks
