Yes you should use a hot plate if it’s a single sided board. If it survived your first try then it should survive more even heating. You could also use the hot plate to just pre-heat it and hit it with hot air briefly (with flux to speed up the process)
Oh, you mean you can damage the dome with hot air? Wish someone would have told me that a couple of years ago… my hot air station only goes to 480C though, maybe that’s why I’ve gotten away with it…
I forget exactly which but I think it’s a medium frosted carclo 10623. Really smooth, great tint and plenty bright. Surprisingly pleasing light quality, actually.
The BOSS of all lights succumb to a tiny crepe pan. This is now my 2nd “mod” that did not require a soldering iron. Granted this was much more delicate than the first but i’m counting it.
Before:
No soldering wires here. Can’t argue with what works I guess? Liberal application of thermal paste, good! Maybe too much but I wont take points away.
Sanded components, come on. AL board for a $110 driver? She’s thicc at least…
The tiny LED tower is actually super cool. The board is drilled and it’s pressed in a tiny hole. The tower has traces running up each side. It really makes this tiny LED appear to be something with much more output.
After:
Crepe ingredients: 1x 2700K, 1x 3500K, 1x 5000K LH351D 90CRI. Better refer to your pics of bond wires to figure out polarity cause I couldn’t make out markings…
One of the two tiny resistors just below the bottom pad tried to fly with his XP-L buddy. Thankfully I noticed and was able to push him back to his home before things got out of hand. Toothpick and just a touch of paste after cleaning her up.
Hey it worked, i’m a little surprised.
Adding some spectrum goodies here for future reference. I believe Oveready uses UCL lenses but this one is from 2016 Q4 so who knows. It’s a thick piece of glass so it probably is. Low (2W), Medium (6.5W), High (17W)
CCT = 3644K (Duv 0.0004)
Color Rendering Index (Ra) = 96.6 [ R9 = 84.4 ]
CCT = 3680K (Duv 0.0001)
Color Rendering Index (Ra) = 96.1 [ R9 = 82.8 ]
CCT = 3705K (Duv –0.0010)
Color Rendering Index (Ra) = 95.5 [ R9 = 80.2 ]
