Catapult Mini V2. A few improvements from perfection.

Hi,

This is not a typical review. It’s just my experience and observations while using it on the trail. The aspects of the light that are important to me. If others disagree that’s fine. We all have our preferences.

Here are a few things that would absolutely improve this cool little light.

I’m on a hiking trail two and a half to three hours every day. In the dark. So I have a lot of experience over the years with my lights and getting to know them well.

  1. I knew there was a step down at 80 seconds( actually 70) , so I am at fault here. However, this is what surprised me about it.

Inside 66°. No fan. No rest. I kept stepping it up until I reached 7 Minutes of using Turbo. The light wasn’t even close to getting hot. I crudely measured the fins at 118°.
Voltage was approximately 3.64 volts.

I have known Eva from Thrunite for 7 years or so. She is very responsive, helpful and informative. She told me the light had both a Timed stepped down and a thermal step down. I don’t doubt her. But I’ve never heard of that, it’s usually one or the other.

She said the thermal step down was 65C/149F. That would be great if it was only a thermal step down which is all it needs. Because it never would have stepped down in those 7 minutes that I had to keep stepping the light back up because of the premature timed step down.

  1. After the timed step down , which is waayy premature , Then the light drops down 358 lumens due to step down. The high setting is basically the same output at 331 lumens…Too big of a gap. HI should be about 600 or 700 lumens. However, that would be negligible if it only had a thermal step down. Since I use the light on Max output until I need to cool it.

To me a thermal step down is the superior one.The light will be protected and it’s not going to be premature as long as they don’t choose like 30 or 40 celsius.

  1. I’m not sure if this is a defect or not. I’ve watched five reviews and no one mentioned it. Not mentioned in the manual either.

When the LED switch light is BLUE or PURPLE it will shut off in about 10 seconds once the light is activated. When that light turns RED it stays on for 40 seconds and shuts off.

I’m pretty sure my original catapult I had five or six years ago that LED indicator light on the switch stayed BLUE the entire time until low voltage. Which is a good thing so you can find the switch.

What is in the manual is that if you press and hold the switch from off for 3 seconds the LED indicator light will go to what they call a breathing LED indicator. I believe that’s something for like the nightstand or to locate it. Because your next click it will go off.

Here are my choices.

  1. Accept the light as it is knowing that I’ll be clicking that switch 50 to 60 times for every time I use(2 battery changes) it to keep it on Turbo. Might be worn out / broken in a couple months.

  2. Sell it.

  3. Get it modified where a step down will not exist ,like all but one of my trail lights(15).

The Lucious 11.

Huge difference in the girth between the two batteries.


Poistive raised contact.



Misty this morning.




David and Goliath.

TN42 CFT90/ Catapult MINI V2

Never, ever been a fan of onboard charging. Neodymium magnet to the rescue for this funky customized cell.

Without.

With

The run times were basically identical despite the almost 200 milliamps of extra capacity.

I despise proprietary batteries and/or charging for flashlight use.
I am sure the motivation is to sell their batteries, but that is not helping me at all.

1 Thank

I was going to recycle the battery and then I realized I had a small enough magnet that might fit.

There’s no way I was going to charge it through the USB port every time. I like having control on the charge current and also I like looking at all the numbers on the Chargers to see the progress.

I forgot something. Besides what I already mentioned.

The primary reason why I don’t like these proprietary/ custom batteries is because we are at the mercy of the manufacturer.

This particular situation is not as common where we can take the battery out and hopefully find a way to charge and have the ability to use other batteries.

With a lot of the bigger lights where you have no choice but to buy a new and very expensive priority battery pack to keep the flashlight working, unless you’re a modder and can figure out a way to using the cells as we know it.

1 Thank

Some positive thoughts. I need to say some good things about this light.

  1. Compact

  2. Built very well

  3. Nice beam profile

  4. Nice tint

  5. Impressive output for such a little guy, primarily the throw.:flashlight:

50 yds. Away.



120 yds. Away.



250 yds. Away

Excellent beam shots. This is how it should be done. :+1:

1 Thank

Welcome Billy!:flashlight:

Thanks.:sunglasses:

Eva from Thrunite got back to me and told me she was mistaken that the light had both a Timed step down and thermal step down. That.
did not surprise me one bit as I told her I’ve never heard of a light that used both of them. That would not make sense. It’s one or the other.

On the other hand she asked me permission to use my beam shots for promotional purposes, I sent her a half dozen or so beam shots that I also have on this thread.

I gave her permission and requested a kickback!

More beam /Trail shots from last night.

My Best buddy Nikko is enjoying the Second beam shot.:sunglasses:





I think the last beam shot in the post above might be from my K1. That may have got mixed in there. I had that light with me also.

With a little creativity and improvisation I was able to use my Eagletac TX25C2 Holster.

I raised it about an inch by using shipping materials.


I think this wraps it up for a little while as far as beam shots go. Some of them are very similar, but different angles and different clarity.



Few more pics. Forgot about my favorite trail.

You can see a White Cross (cemetery) up on the hill across the river.

I used Google Earth for the measurement.

250 yards

Natural

Zoom

More Zoom
