Jaxman X1s series are ready to sell

Commercial Sellers' Spot
1

hi,dear all,those days,I was focusing on a new single 26650/18650 flashlight,the X1s. X1s is a developed model of the X1.
The out look of X1s.






and the some detail picture:


We want the X1s be a short,powerful,and solid flashlight. It should has a good waterproof,well holding feeling,and a practical tool for the user.We produce two version, the throw and the flood.

the flood version is based on XHP50 famlily lamps. we can use XHP50,XHP50.2.We now can provide the XHP50 in 4 tints, and XHP50.2 in 1 tint—–6000K coolwhite.

the throw version is based on a 3535 size LED—- XHP35 HI. and a smooth reflector.

we have 3 kinds of tint xhp35hi now.

We decide the last modes are: High 100% ,Middle 40, Low 10. and another working mode—-fast stobe at 8hz, at any mode,if the user fast click the switch in 0.2S, the flashlight will go into fast strobe mode. And once the user shut off the power and turn on again, the flashlight will go into the former mode before fast strobe.

Because in the trial production we use a different mode: H,M,L,breath strobe and fast stobe(2 fast click), so we have some trial version in flood X1s XHP50.

The driver of X1s is a boost one,so the current is some big, max. can up to 7A. so we use a larger tactical switch. This switch is some different with the other JAMXAN flashlight,
the tail switch will on when you press it lightly and locked if you press hardly. And so the mode changing orperation must be finished before you lock the switch.

As the shelf or drill,we think they are all good solutions. To choose which is only for the technical convenience.This X1s is no drill.

We have to repeat one question, the X1s is based on standard 26650/18650 battery.Any battery with a protection board maybe not well accord to X1s.There is no a standard of all repacked batteries, some are thicker,some are longer, no standard size…We promise the max OD of the battery is 26.5mm, the Max. Length is 68mm. Otherwise it will cant work.

Another probelem is, all protect battery maybe cant discharge at >6A. so if so, the 20W flood version may cant work, because it need a bigger input current.

All the 2 kind of X1s are working at the official max. power in high mode. the flood version is 20w max,and the throw version is 13w max.

As a new product, we set a 15% off. one price is including shipping fees,—-since most buyer like the price including shipping fees, I want make a try. one is without shipping fees.so the price is some different. I do like a directly thinking method,but the market is like an not directly way, then I want try it too.

Any question, pls mail me zx.bao@foxmail.com or here.

Best wishes.

2

This looks great!

3

Hi Jaxman,

1. You should add some links to your post:

Jaxman X1s throw

Jaxman X1s flood

2. What’s the difference between “breathing” strobe and “fast” strobe? Did you remove “breathing” strobe from the final UI?

4

Guess what? I just ordered one from the aliexpress. Its the xhp 35 cool white version…

5

How come no estimates throw number? I would like to know how it competes with the utorch and manker. They have it right around 700 meters.

6

Looks great Jaxman!
Nice bezel

7

“Edge covered glass sealing ring”. Wow. That’s just awesome. :+1:

8

Yeah, much better than a squiched o-ring.
Olight do that from long time now, Jaxman made the right choice with that !

9

First time I watched I was convinced the lens would shatter, but it didn’t. Then I read in JM’s review about the rubber ring surrounding the lens entirely… Really nice feature.

10

thank you very much for your adding links.

the final UI is without breathing strobe. the breathing strobe is a trial samples’ UI.

now we have only few this UI flashlight in XHP50 version X1s. The XHP35 HI X1s now is all the H M L (hidden fast strobe) UI solution.
And we also can provide the final UI XHP50 X1s to BLFers, only need you mention it and let us know it.

11

hi, it is hard to say how long a flashlight can throw.
I want submit this question to our users, let they tell us.
ra
the xhp35 hi works at 1.05A max. in high mode, the official max. current according to the datasheet issued by CREE.

12

I know that your business plan is to provide reliable flashlights but you could safely overdrive the CREE emitters at 200% and still be safe.
At 2A, the XHP35 would REALLY throw and still be cool enough given the mass of the X1s !

13

Jaxman can overdrive that driver and call it the X1mod. Since we at BLF strive to push the limits of LED technology. Not let it work at suggested specs but at what is possible without compromising on safety

14

At 1 amp, it’s not worth it to me personally.

I will buy it overdriven at 2+ amps. All the extra cooling features need to be worth it.

Please jaxman, offer it to us with higher amps if you are able to. :slight_smile:

This light is soo close to what I’ve been looking for!

15

Great construction for a budget light!

I dont see the XHP50.2 on AliExpress, will it be added? Any specific reason why warm white or neutral xhp50.2 isn’t an option?

16

Exactly my thinking. I had the light in my shopping cart until I read only 1 amp.
And at only 1300 Lumen’s, theres nothing a xpl hi can’t do. Please take advantage of the xhp35 hi and the nice big light for heat sink.

17

if the XHP35hi has the same output as a XPLhi in terms of lumens, still ver nice, means reliable, no heat issues AND bigger lightsource so fatter beam.

18

I do not want to let a LED working at a non-official condition.
sorry for that, even I really can realize a double current, I would not do it.

19

xhp50.2 is really easy to realize. we have LED on hand ,coolwhite. if friends need,pls tell us,we can make a 50.2 light for you.

Due to busy work,we have not prepared ready for the link of 50.2

20

thanks for your support on my thinking.
what I most care, is that: any one Jaxman flashlight must be a solid tool. solid is first.
and what is more, we should find the balance of power consumption and the efficiency.
a 1300lm x1 flashlight has been a good thrower.That is my frankly review on the extra-power input.

BR
