HAIKELITE MT01 TREKKER
Notice!
This Haikelite MT01 is provided free by Banggood for my honest and unbiased review no other payments are received other then the flashlight provided, this will not change how i review any Haikelite products or any other products that i will be reviewing in the future. All my other Haikelite flashlights (MT03, MT07, SC01, MT02) were purchased with my own money.
Product Link: Haikelite MT01 (my link to Haikelite MT01 on Banggood, not affiliate link)
Discount Code (20% off): 75c9fe
Introduction
This is my 5th Haikelite flashlights that i reviewed. My first Haikelite was MT07 and it was my first ever entry to a thrower lights, i used to have Aspherical Maglite but that was a moded light and i like the MT07 alot because of how different it is compared to other thrower since then i keep buying more and more Haikelite flashlight. Haikelite seems to have different design compared to other manufacturers, for starters most new startup would start by producing a single 18650 pen-light style with tail clicky but not Haikelite their design is simply standout among the crowded flashlight market and honestly that what made me attracted to Haikelite.
Pro:
Simple UI with one electronic button and click or click-hold action.
Using latest gen XHP50.2 emitter.
Available in NW version and black anodizing
Quite sounding clicky button which i like and with enough tactile feedback and not mushy not as engaging as the clicky in Convoy L6
Perfect size for palm gripping, fits nice in your palm.
It is possible to run on single or up to three 18650s as long as your single 18650 is high drain
Regulated boost driver.
No obvious flaws and no blemish or imperfection on the surface and finishes.
Able to tail-stand but due to the tailcap triangular design it is not very stable.
Lanyard Hole at the tailcap.
Cons:
Double click to Strobe, i hate this. It is like that Haikelite intended this light to be a tactical self defense kind of light which i dont it is but the size and weight of it could very well be a weapon if you hit someone on the head (not recommended!)
Hot on Turbo.
Not enough flat surface to avoid rolling over your table, the flat side of the switch is barely enough to stop the light from rolling similar to MT02 which has the same inherent design flaws so be careful.
No spring on the head so bumping/droping the light could switch it off and damage the battery positive.
My MT01 and MT02 have an inadequate spring soldering job, which could be the solder being used or the material that coats the spring that make the solder harder to stick and the spring only soldered one sided. Haikelite are already aware of the problem and said they will fixed all lights that are currently in their hands. It is recommended that you check your spring and re-soldered them just to make sure.
Data from manufacturer
Specifications:
—Emitter: CREEXHP50 V2 CW / 5000K NW / CREE MTG2
—Aluminum Alloy body with HAIII Anodize black surface Finish
—Battery: 3x18650 / 18700 in parallel (works on all kinds of 18650 battery, flat-top or button top)
—Aluminum Reflector
— Ultra Clear Double-sided AR coated toughened Glass lens (99%light transmittance)
— IPX8 Waterproof underwater 2 meters
—Max Brightness: CW 2500 Lumens
—Shot distance: 300 meters
—Full Current Regulation; Boost driver ; Real driver efficiency > 93%
— Build-in Anti-reverse protection in flashlight driver. If you put the battery reversely, there is no drain coming through.
— Anti-discharge protection;
—Brightness Level:
Low Low 50lumens 75 hrs
Low 250 Lumens 15 hrs
Middle 500 Lumens 5 hrs
High 1000 Lumens 105 minutes
Double click Turbo: 2500 Lumens
When off , a long press for 2 seconds to access Strobe
Size: 135mm length x 51mm Head x 45mm body
Weight：280 Gram
UI:
Click on — Click off
Hold switch to change mode ; With Last mode momery
Dolbe click Hidden Turbo
When off , a long press for 2 seconds to access Strobe
Lockout function:
A fast click followed by a long click to lockout the flashlight ; Repeat to unlock; Loosing the head or tail cap a bit can lockout the light as well.
>Battery power detection:
In off status, Press 4 seconds to activate battery power detection function. battery >50% flash 3 times ; battery >25% <50%flash 2 times ; battery <25% flash 1 time.
Note:
The text was taken directly from Haikelite website which some info are obviously wrong:
- Double click Hidden Turbo instead double click will go straight to Strobe annoying!
- MT01 doesn’t have battery power level indicator unlike SC01 and MT02 so the above text is not correct i find this odd, holding the button while the light is off does nothing.
Attention!!
This have come to my attention that the soldering on the spring is not good (reported by few users) even on the last batch on my MT01(15 of August 2017). Solution is to re-soldered them. These boards came from both of my MT01 and MT02.
Haikelite already aware of the Problem and said already fixing the problem with the lights they have in stock.
The Haikelite way of encasing the light for shipping, the obligatory black box ^:)
One of the tab already broken off and stored inside with the light, probably done by the courier when they opened the light? thoughtful of him to sneak it back inside
What it look like inside when arrived
Hmm what missing inside? O-rings, weird it is just empty plastic clip with no O-rings inside. BTW i got extra O-rings from my MT03 maybe they decided that i have already enough O-rings. MT03 O-rings are too big for this light mind you.
The flashlight in hand, the matte silver finished is beautiful. Will Haikelite produce another color in the future? Maybe Desert Tan?
All alone in the wilderness.
The flashlight do look beautiful on sunlight
The OP reflector, with large Emitter such as XHP50.2 this is trully made for medium illumination
The reflector, lens, bezel assembly in the exact order when assembled.
The XHP50.2 emitter, there is a centering ring (not in picture) and the star is screwed down.
This is where you insert the battery, not from the tail.
My Samsung 30Q needs solder blob while my LG HG2 doesnt.
Samsung 30Q sits higher in MT01 compared to MT02(left)
The tail assembly sans the tailcap
The MT01 seems to be using slightly higher spring compared to my MT02 or could be my MT02 springs already weakened?
Look down the battery tube toward the head
Deep ribbing on the head near the Switch (metal switch)
MT01 with provided lanyard, good quality too. i dont use lanyard.
One big happy family (MT07, MT03, MT01, MT02, SC01 from left to right)
Compared to Convoy L6 (most people here probably own Convoy L6)
Reflector size comparison to Convoy L6
Compared to other 18650 lights (Emisar D4, Astrolux S41, Haikelite MT01, BLF A6)
Reflector size comparison (Astrolux S41, BLF A6, Haikelite MT01, Emisar D4)
Haikelite MT01 and Haikelite MT02 comparison
MT02(left) and MT01, both looks identical with different character
Again Haikelite MT01 and Haikelite MT02
The Haikelite MT01 has serial number and CE ROHS text while the MT02 doesnt, this particular tail-cap design make the light unstable while tail-standing. This design was probably decided so they could have hole for the lanyard.
Haikelite MT02(left) and Haikelite MT01(right)
Head assembly Haikelite MT02(left) and Haikelite MT01, look like different driver is being use.
The diamond knurling tough to clean when dirt get in between.
Parts of the Tube and tail are interchangeable between MT01 and MT02. Lego light?
Another Angle.
The same boards being use not surprising both lights running 3x18650 in paralel
Burn Test on Turbo
Ambient temperature 29C
1 Minute
2 Minute
3 Minutes
4 Minutes
5 Minutes
6 Minutes
7 Minutes 30 Seconds
9 Minutes (i need glove to handle the flashlight at this temperature) even the tube is hot.
Beamshots:
Ignore the text this supposed to be MT01 not MT02 (i’ll update the picture when it is dark)
This is the Real MT02 (sorry for that)
Haikelite SC01
Haikelite MT07
Haikelite MT03
Convoy L6
Emissar D4 Nichia
Video of MT01 MT02 and SC01
https://www.youtube.com/watch?v=xfKVwbkt9bU
Several tests
Battery draw Single LG HG2
low = 0.007A
mid1 = 0.46A
High = 2.03A
Turbo = 6.01A
Ceiling bounce test comparative result.
Sumary
MT01 and MT02 look identical but in paper the are very well a different lights, both using smooth or orange peel reflector and both using different emitter XHP50.2 and XHP35. The MT01 is intended for more general purpose light although not as floody as SC02 the MT01 still have a nice soft hotspot to spill transition that not as blinding as the MT02 and still have throw when needed. I would rank the light from throw to flood in this order SC01 > MT02 >MT01 >SC02 the SC02 being the most flood. I found that i like the MT01 than the MT02 for its softer hotspot, but the UI is letting it down, after using SC01 and MT02 for a while now double click to strobe is annoying, being able to go to turbo in instant is a big plus for me instead of strobe i normaly keep my light on low or medium and use turbo once when needed without having to cycle through the mode.
I wished that Haikelite could unify all their flashlight UI, but i think they trying to build light with various combinations and at the same time try to cater for “tactical” and “self defense” light crowds this time with MT01.
Would i recommend MT01? yes despite its downfall the beam is nice enough without being to floody if you are new to Haikelite then the UI should be easy, but i am accustomed to MT02 and SC01 flashlights and using MT01 is like learning all over again, going to strobe accidentally is indeed not nice!
